Allen Bradley 1771-P6R Redundant Power Supply Module

Allen Bradley Redundant Power Supply Module

Item No.:
Allen Bradley 1771-P6R
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1771-P6R Redundant Power Supply Module

Each power supply module has two jumpers located at the back of the power supply near the edge connectors. The jumper selection provides the proper voltage regulation for the different power supply configurations. The power supply can be configured to support local or remote sensing by setting the jumpers.Each power supply in a redundant system must be assigned a different identification number. To do this, you must set the I.D. selection switches located on the left side of the module (figure 2). A cutout in the metal cover of the module provides access to these switches.Switches 1 through 4 are for the power supply identification number. Switches 5 and 6 are set based on the configuration zone.

Allen Bradley 1771-P6R Redundant Power Supply Module Technical drawing:

330171-10-24-05-02-00
