Allen Bradley 1771-RTP4 I/O Module

Allen Bradley I/O Module

Item No.:
Allen Bradley 1771-RTP4
Payment:
T/T
Product origin:
Sweden (SE)
Color:
Mental
Goods_stock:
999
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

Allen Bradley 1771-RTP4 I/O Module

For the temperature control module, you must use the 1771-RTP1 Remote termination panel. The remote termination panels are designed for mounting on standard DIN 1 or DIN 3 mounting rails. Mounting dimension are shown in Figure 2.2.Connect the other end of each cable to the remote termination panel. You need two cables per module. Connect one cable from the top connecter on the module to the right connector on the panel. Connect the other cable from the bottom connector on the module to the left connector on the panel. At the panel, use the thumb screws to lock the connector in place. The proper orientation of the cables is shown in Figure 2.4.

Allen Bradley 1771-RTP4 I/O Module Technical drawing:

IC660BBA024
