General Electric IC200ALG620 Analog Input RTD Module

General Electric IC200ALG620 Analog Input RTD Module

The Analog Input RTD Module is an intelligent module that accepts input signals from up to 4 RTD input devices and provides input data with 16 bits of resolution.

Module features include:

ƒ Selectable resistance measurements in tenths of ohms, tenths

of degrees Fahrenheit, or tenths of degrees Celsius

ƒ Individual channel configuration

ƒ Selectable resistance ranges: 0 – 500 ohms and 0 – 3000

ohms

ƒ Selectable RTD input as resistance or temperature (Celsius or

Fahrenheit)

ƒ Reports high/low, underrange/overrange, open wire and input

short alarms.

ƒ Two data acquisition rates based on 50 Hz and 60 Hz line

frequencies

ƒ Configurable channel activation
