General Electric IC660BLD025 Genius IO System Module

General Electric Genius IO System Module

Item No.:
General Electric IC660BLD025
Payment:
T/T
Product origin:
USA
Color:
Mental
Goods_stock:
100
Shipping port:
HongKong
Lead Time:
1-2 Days

Product Details

General Electric IC660BLD025 Genius IO System Module

The power input terminal board provides two terminals for connecting 48 VDC power and an additional terminal for system and noise ground. Power input connections should be made with copper AWG #16 (1.33 mm 2 ) through AWG #12 (3.31 mm 2 ) wire rated for 75?C (167?F). Each terminal can accept solid or stranded wires, but the wires into any given terminal should be the same
type and size. It is recommended that the GND terminal on the power supply be connected to the GND terminal on the rack and to earth using copper AWG #12 (3.3 mm 2 ) wire rated for 75?C (167?F) and a ring terminal to ensure adequate grounding. Use of a nut and star washer for each wire on
the GND lug is recommended.
